Feature
User-friendly operational interface.
Automatic adjusted pressure.
Automatic thickness detection.
Brush rolling linear velocity fixed.
Application
Removal of plugging resin.
Pre-treatment for D/F,S/M,ENIG.
Pre and Post-treatment for PTH.
Removal of resin from steel.
|
|
|
High precision servo pressure regulator, high stability spindle and transmission mechanism, convenient brush removal and replacement design. | Highly accurate plate thickness measurement device for accurate detection and switching of thickness before brushing and grinding. | Chinese/English man-machine numerical control operating system, graded authority operation management. |
Specifications
Items | Unit | Parameter |
Panel thickness | mm | 0.3-3.2(Other sizes can be customised) |
Pass Size | mm | 250×250-710×710 |
Effective Width | mm | 720 |
Revolution | rpm | 1800-2400（constant velocity 848m/min） |
Oscilltion | cpm | 425 |
Convery Speed | M/Min | 0.5-5.0 |
Pass line | mm | 950±15 |
Machine Size | mm | L2505×W1518×H1350 |
Weight | Kg | 2500 |
Power | - | 13KW 3-phase 380V |
